224-310KW康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯电站用打着机然油城市发展性好: 高级的然油调整操作体系，代表性的STC、ESTC 分等级调整操作体系，特殊性装修设计的连杆顶部烧室，压力发射然油，有效雾化吸入，烧有效。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯生产发电用发起机瞬态效能表现出色: 高品质的发起机整体风格设定，协助康明斯奇特的EFC机系统，把控好精确高，反映时刻快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯发电站用发起机升热效率高: 整体风格来设计紧身.形态布局正确，进行有序。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷仪器 QSNT. QSK19. QSK38. QSK50需要满足国非道路交通第三步时候及南美Tier2. Tier 3尾气排放法律规范需求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零维修工具可求性好， 发起机加载及服务器维护养生保健方便，成本费用低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

工作功率使用范围 Power Range   224-310KW型号规格 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L形态长宽比 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净产品 Dry Weight   940kg

224-310KW康明斯发电厂用汽车发因素的性能：体型小， 压缩视频比较高， 防雨百叶热空气调温，有利无法，手机车载导航电的都喜欢选用。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打火机技术参数	通用瓦数(kW)Prime Power	备用电源工率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
